#ipmitool -H $IP -U $admin -P $admin -I lanplus -C 2 sol activate nokeepalive

其中 -I 是interface的意思因為 BMC是走serial over Lan的方式故進行SOL console連線時必需指定其intetface.
再者-C 指的是連線的加密方式,以本指令來說是不做AES加密,可增加其效率,但在internet上也增加其風險性,但詳情還必需視各家BMC spec定義做為結論.
最 nokeepalive的參數有玩過防火牆的人就應該很熟悉了,若該次連線有需要長時間連線且不可斷線則nokeepalive的參數就有其必要性囉,同時這也是筆者最常用的IPMI TOOLS了.



Yang Chun Yi 發表在 痞客邦 留言(1) 人氣()

$sudo vim /etc/network/interfaces

auto eth0
iface eth0 inet static #改成static
address 192.168.1.1
netmask 255.255.255.0
network 192.168.1.0   #可不寫
broadcast 192.168.1.255 #可不寫

gateway 192.168.0.253
dns-nameserver 192.168.0.253 8.8.8.8


$sudo /etc/init.d/networking restart

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

檔案格式 檔名格式 直接安裝與否 內含程式類型 可否修改參數並編譯
RPM xxx.rpm 可 已編譯 不可
SRPM xxx.src.rpm 不可 未編譯之原始碼 可

1. rpmbuild --rebuild:這個選項會將後面的 SRPM 進行『編譯』與『打包』的動作,最後會產生 RPM 的檔案,但是產生的 RPM 檔案並沒有安裝到系統上。當你使用 --rebuild 的時候,最後通常會發現一行字體:
Wrote: /usr/src/redhat/RPMS/i386/pkgname.i386.rpm
這個就是編譯完成的 RPM 檔案囉!這個檔案就可以用來安裝啦!安裝的時候請加絕對路徑來安裝即可!

2.rpmbuild --recompile:這個動作會直接的『編譯』『打包』並且『安裝』囉!請注意, rebuild 僅『編譯並打包』而已,而 recompile 不但進行編譯跟打包,還同時進行『安裝』了!

3. 完成後,可至/usr/src/redhat/RPMS/x86_64(or i386)安裝。

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

通常我們在os下有安裝任何的硬體都會經過一個安裝driver的步驟,如果今天我們對driver的版本有問題的話,不知道大家是如何linux下去查看driver呢?
今天提供一個比較簡單的方法,讓大家可以查看一下。
#lsmod
#modinfo drivername
這樣子就可以去查尋driver的版本了。
或是
#ethtool -i ethx

Yang Chun Yi 發表在 痞客邦 留言(2) 人氣()

一、套件:
[root@samyang etc]# rpm -qa |grep bind
bind-libs-9.3.6-4.P1.el5_4.2
bind-chroot-9.3.6-4.P1.el5_4.2
ypbind-1.19-12.el5
bind-9.3.6-4.P1.el5_4.2
bind-utils-9.3.6-4.P1.el5_4.2
[root@samyang etc]# rpm -qa |grep caching-nameserver
caching-nameserver-9.3.6-4.P1.el5_4.2

二. 先前準備:
1、[root@samyang etc]# cat /etc/resolv.conf

search localdomain
#nameserver 8.8.4.4
#nameserver 168.95.1.1
#nameserver 208.67.222.222
nameserver 192.168.11.2
2、[root@samyang etc]# cat /etc/sysconfig/network
NETWORKING=yes
NETWORKING_IPV6=no
HOSTNAME=samyang.com.tw

三、主設定檔:
1、/var/named/chroot/etc
[root@samyang etc]# ls
named.conf named.rfc1912.zones
2、[root@samyang named]# ls
192.168.11.zone samyang.com.tw.zone

四、設定檔修改:
1、
[root@samyang etc]# cat /var/named/chroot/etc/named.conf
//
// named.caching-nameserver.conf
//
// Provided by Red Hat caching-nameserver package to configure the
// ISC BIND named(8) DNS server as a caching only nameserver
// (as a localhost DNS resolver only).
//
// See /usr/share/doc/bind*/sample/ for example named configuration files.
//
// DO NOT EDIT THIS FILE - use system-config-bind or an editor
// to create named.conf - edits to this file will be lost on
// caching-nameserver package upgrade.
//
acl "mynic" { 192.168.11.2; 127.0.0.1; };
acl "mynet" { 192.168.11.0/24; 127.0.0.0/8; };
options {
listen-on port 53 { mynic; };
listen-on-v6 port 53 { ::1; };
directory "/var/named";
dump-file "/var/named/data/cache_dump.db";
statistics-file "/var/named/data/named_stats.txt";
memstatistics-file "/var/named/data/named_mem_stats.txt";

// Those options should be used carefully because they disable port
// randomization
// query-source port 53;
// query-source-v6 port 53;

allow-query { mynet; };
allow-recursion { mynet; };
allow-transfer { mynet; };
allow-query-cache { mynet; };
};
logging {
channel default_debug {
file "data/named.run";
severity dynamic;
};
};
view localhost_resolver {
match-clients { any; };
match-destinations { any; };
recursion yes;
include "/etc/named.rfc1912.zones";
};
2、
[root@samyang etc]# cat /var/named/chroot/etc/named.rfc1912.zones
// named.rfc1912.zones:
//
// Provided by Red Hat caching-nameserver package
//
// ISC BIND named zone configuration for zones recommended by
// RFC 1912 section 4.1 : localhost TLDs and address zones
//
// See /usr/share/doc/bind*/sample/ for example named configuration files.
//
zone "." IN {
type hint;
file "named.ca";
};

zone "localdomain" IN {
type master;
file "localdomain.zone";
allow-update { none; };
};

zone "localhost" IN {
type master;
file "localhost.zone";
allow-update { none; };
};

zone "0.0.127.in-addr.arpa" IN {
type master;
file "named.local";
allow-update { none; };
};

zone "0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.ip6.arpa" IN {
type master;
file "named.ip6.local";
allow-update { none; };
};

zone "255.in-addr.arpa" IN {
type master;
file "named.broadcast";
allow-update { none; };
};

zone "samyang.com.tw" IN {
type master;
file "samyang.com.tw.zone";
allow-update { none; };
};

zone "11.168.192.in-addr.arpa" IN {
type master;
file "192.168.11.zone";
# allow-update { none; };
};
3、
[root@samyang named]# cat /var/named/chroot/var/named/samyang.com.tw.zone
$TTL 86400
samyang.com.tw. IN SOA dns.samyang.com.tw. root.dns.samyang.com.tw. (
2010020701 ; serial (d. adams)
3H ; refresh
15M ; retry
1W ; expiry
1D ) ; minimum

IN NS dns.samyang.com.tw.
dns IN A 192.168.11.2
ftp IN A 192.168.11.3
www IN A 192.168.11.4
IN AAAA ::1

4、
[root@samyang named]# cat /var/named/chroot/var/named/192.168.11.zone
$TTL 86400
11.168.192.in-addr.arpa. IN SOA dns.samyang.com.tw. root.dns.samyang.com.tw. (
2010020701 ; Serial
28800 ; Refresh
14400 ; Retry
3600000 ; Expire
86400 ) ; Minimum
IN NS dns.samyang.com.tw.
2 IN PTR dns.samyang.com.tw.
3 IN PTR ftp.samyang.com.tw.
4 IN PTR www.samyang.com.tw.

5、
[root@samyang Desktop]# cat /etc/resolv.conf
search localdomain
#nameserver 168.95.1.1
#nameserver 8.8.8.8
nameserver 192.168.11.2

6、
[root@samyang Desktop]# cat /etc/hosts
# Do not remove the following line, or various programs
# that require network functionality will fail.
127.0.0.1 localhost.localdomain localhost
::1 localhost6.localdomain6 localhost6
192.168.11.2 dns.samyang.com.tw
192.168.11.18 station18.samyang.com.tw
192.168.11.25 station25.samyang.com.tw

7、
[root@samyang sysconfig]# cat /etc/sysconfig/network
NETWORKING=yes
NETWORKING_IPV6=no
HOSTNAME=samyang.com.tw


五、注意事項:
1、
[root@samyang named]# ls -al /var/named/chroot/var/named
總計 104
drwxr-x--- 4 root named 4096 2月 7 15:57 .
drwxr-x--- 6 root named 4096 1月 21 00:33 ..
-rw-r----- 1 root named 573 2月 7 15:29 192.168.11.zone
drwxrwx--- 2 named named 4096 2月 7 14:15 data
-rw-r----- 1 root named 198 2月 7 15:32 localdomain.zone
-rw-r----- 1 root root 195 2月 7 15:19 localhost.zone
-rw-r----- 1 root named 427 1月 21 00:33 named.broadcast
-rw-r----- 1 root named 1892 1月 21 00:33 named.ca
-rw-r----- 1 root named 424 1月 21 00:33 named.ip6.local
-rw-r----- 1 root root 426 2月 7 15:22 named.local
-rw-r----- 1 root named 427 1月 21 00:33 named.zero
-rw-r----- 1 root named 369 2月 7 15:33 samyang.com.tw.zone
drwxrwx--- 2 named named 4096 7月 27 2004 slaves
2、
[root@samyang etc]# ls -al /var/named/chroot/etc
總計 64
drwxr-x--- 2 root named 4096 2月 7 17:40 .
drwxr-x--- 6 root named 4096 2月 7 13:54 ..
-rw-r--r-- 1 root root 724 1月 31 11:24 localtime
-rw-r----- 1 root root 1230 2月 7 13:46 named.caching-nameserver.conf.backup
-rw-r----- 1 root named 1367 2月 7 16:26 named.conf
-rw-r----- 1 root named 1066 2月 7 16:26 named.rfc1912.zones
-rw-r----- 1 root root 955 2月 7 13:57 named.rfc1912.zones.backup
-rw-r----- 1 root named 113 1月 20 00:04 rndc.key

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

一、

套件:

[root@samyang var]# rpm -qa|grep vsftpd

vsftpd-2.0.5-16.el5_4.1



二、設定檔:

1、

[root@samyang var]# cat /etc/vsftpd/vsftpd.conf

# Example config file /etc/vsftpd/vsftpd.conf

#

# The default compiled in settings are fairly paranoid. This sample file

# loosens things up a bit, to make the ftp daemon more usable.

# Please see vsftpd.conf.5 for all compiled in defaults.

#

# READ THIS: This example file is NOT an exhaustive list of vsftpd options.

# Please read the vsftpd.conf.5 manual page to get a full idea of vsftpd's

# capabilities.

#

# Allow anonymous FTP? (Beware - allowed by default if you comment this out).

anonymous_enable=YES

no_anon_password=YES

anon_root=/var/ftp

chroot_local_user=YES

passwd_chroot_enable=YES

#

# Uncomment this to allow local users to log in.

local_enable=YES

#

# Uncomment this to enable any form of FTP write command.

write_enable=YES

#

# Default umask for local users is 077. You may wish to change this to 022,

# if your users expect that (022 is used by most other ftpd's)

local_umask=022

#

# Uncomment this to allow the anonymous FTP user to upload files. This only

# has an effect if the above global write enable is activated. Also, you will

# obviously need to create a directory writable by the FTP user.

#anon_upload_enable=YES

#

# Uncomment this if you want the anonymous FTP user to be able to create

# new directories.

#anon_mkdir_write_enable=YES

#

# Activate directory messages - messages given to remote users when they

# go into a certain directory.

dirmessage_enable=YES

#

# The target log file can be vsftpd_log_file or xferlog_file.

# This depends on setting xferlog_std_format parameter

xferlog_enable=YES

#

# Make sure PORT transfer connections originate from port 20 (ftp-data).

connect_from_port_20=YES

#

# If you want, you can arrange for uploaded anonymous files to be owned by

# a different user. Note! Using "root" for uploaded files is not

# recommended!

#chown_uploads=YES

#chown_username=whoever

#

# The name of log file when xferlog_enable=YES and xferlog_std_format=YES

# WARNING - changing this filename affects /etc/logrotate.d/vsftpd.log

#xferlog_file=/var/log/xferlog

#

# Switches between logging into vsftpd_log_file and xferlog_file files.

# NO writes to vsftpd_log_file, YES to xferlog_file

xferlog_std_format=YES

#

# You may change the default value for timing out an idle session.

#idle_session_timeout=600

#

# You may change the default value for timing out a data connection.

#data_connection_timeout=120

#

# It is recommended that you define on your system a unique user which the

# ftp server can use as a totally isolated and unprivileged user.

#nopriv_user=ftpsecure

#

# Enable this and the server will recognise asynchronous ABOR requests. Not

# recommended for security (the code is non-trivial). Not enabling it,

# however, may confuse older FTP clients.

#async_abor_enable=YES

#

# By default the server will pretend to allow ASCII mode but in fact ignore

# the request. Turn on the below options to have the server actually do ASCII

# mangling on files when in ASCII mode.

# Beware that on some FTP servers, ASCII support allows a denial of service

# attack (DoS) via the command "SIZE /big/file" in ASCII mode. vsftpd

# predicted this attack and has always been safe, reporting the size of the

# raw file.

# ASCII mangling is a horrible feature of the protocol.

#ascii_upload_enable=YES

#ascii_download_enable=YES

#

# You may fully customise the login banner string:

#ftpd_banner=Welcome to blah FTP service.

#

# You may specify a file of disallowed anonymous e-mail addresses. Apparently

# useful for combatting certain DoS attacks.

#deny_email_enable=YES

# (default follows)

#banned_email_file=/etc/vsftpd/banned_emails

#

# You may specify an explicit list of local users to chroot() to their home

# directory. If chroot_local_user is YES, then this list becomes a list of

# users to NOT chroot().

#chroot_list_enable=YES

# (default follows)

#chroot_list_file=/etc/vsftpd/chroot_list

#

# You may activate the "-R" option to the builtin ls. This is disabled by

# default to avoid remote users being able to cause excessive I/O on large

# sites. However, some broken FTP clients such as "ncftp" and "mirror" assume

# the presence of the "-R" option, so there is a strong case for enabling it.

#ls_recurse_enable=YES

#

# When "listen" directive is enabled, vsftpd runs in standalone mode and

# listens on IPv4 sockets. This directive cannot be used in conjunction

# with the listen_ipv6 directive.

listen=YES

#

# This directive enables listening on IPv6 sockets. To listen on IPv4 and IPv6

# sockets, you must run two copies of vsftpd whith two configuration files.

# Make sure, that one of the listen options is commented !!

#listen_ipv6=YES



pam_service_name=vsftpd

userlist_enable=YES

tcp_wrappers=YES



2、

[root@samyang var]# cat /etc/hosts.allow

#

# hosts.allow This file describes the names of the hosts which are

# allowed to use the local INET services, as decided

# by the '/usr/sbin/tcpd' server.

#

vsftpd: 192.168.11.



3、

[root@samyang var]# cat /etc/hosts.deny

#

# hosts.deny This file describes the names of the hosts which are

# *not* allowed to use the local INET services, as decided

# by the '/usr/sbin/tcpd' server.

#

# The portmap line is redundant, but it is left to remind you that

# the new secure portmap uses hosts.deny and hosts.allow. In particular

# you should know that NFS uses portmap!

vsftpd: ALL

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

一、套件:
[root@station18 ftp]# rpm -qa |grep httpd
httpd-tools-2.2.14-1.fc12.i686
system-config-httpd-1.4.6-1.fc12.noarch
httpd-manual-2.2.14-1.fc12.noarch
httpd-2.2.14-1.fc12.i686

二、設定檔:

[root@station18 ftp]# cat /etc/httpd/conf/httpd.conf
#
# This is the main Apache server configuration file. It contains the
# configuration directives that give the server its instructions.
# See for detailed information.
# In particular, see
#
# for a discussion of each configuration directive.
#
#
# Do NOT simply read the instructions in here without understanding
# what they do. They're here only as hints or reminders. If you are unsure
# consult the online docs. You have been warned.
#
# The configuration directives are grouped into three basic sections:
# 1. Directives that control the operation of the Apache server process as a
# whole (the 'global environment').
# 2. Directives that define the parameters of the 'main' or 'default' server,
# which responds to requests that aren't handled by a virtual host.
# These directives also provide default values for the settings
# of all virtual hosts.
# 3. Settings for virtual hosts, which allow Web requests to be sent to
# different IP addresses or hostnames and have them handled by the
# same Apache server process.
#
# Configuration and logfile names: If the filenames you specify for many
# of the server's control files begin with "/" (or "drive:/" for Win32), the
# server will use that explicit path. If the filenames do *not* begin
# with "/", the value of ServerRoot is prepended -- so "logs/foo.log"
# with ServerRoot set to "/etc/httpd" will be interpreted by the
# server as "/etc/httpd/logs/foo.log".
#

### Section 1: Global Environment
#
# The directives in this section affect the overall operation of Apache,
# such as the number of concurrent requests it can handle or where it
# can find its configuration files.
#

#
# Don't give away too much information about all the subcomponents
# we are running. Comment out this line if you don't mind remote sites
# finding out what major optional modules you are running
ServerTokens OS

#
# ServerRoot: The top of the directory tree under which the server's
# configuration, error, and log files are kept.
#
# NOTE! If you intend to place this on an NFS (or otherwise network)
# mounted filesystem then please read the LockFile documentation
# (available at );
# you will save yourself a lot of trouble.
#
# Do NOT add a slash at the end of the directory path.
#
ServerRoot "/etc/httpd"

#
# PidFile: The file in which the server should record its process
# identification number when it starts.
#
PidFile run/httpd.pid

#
# Timeout: The number of seconds before receives and sends time out.
#
Timeout 120

#
# KeepAlive: Whether or not to allow persistent connections (more than
# one request per connection). Set to "Off" to deactivate.
#
KeepAlive Off

#
# MaxKeepAliveRequests: The maximum number of requests to allow
# during a persistent connection. Set to 0 to allow an unlimited amount.
# We recommend you leave this number high, for maximum performance.
#
MaxKeepAliveRequests 100

#
# KeepAliveTimeout: Number of seconds to wait for the next request from the
# same client on the same connection.
#
KeepAliveTimeout 15

##
## Server-Pool Size Regulation (MPM specific)
##

# prefork MPM
# StartServers: number of server processes to start
# MinSpareServers: minimum number of server processes which are kept spare
# MaxSpareServers: maximum number of server processes which are kept spare
# ServerLimit: maximum value for MaxClients for the lifetime of the server
# MaxClients: maximum number of server processes allowed to start
# MaxRequestsPerChild: maximum number of requests a server process serves

StartServers 8
MinSpareServers 5
MaxSpareServers 20
ServerLimit 256
MaxClients 256
MaxRequestsPerChild 4000


# worker MPM
# StartServers: initial number of server processes to start
# MaxClients: maximum number of simultaneous client connections
# MinSpareThreads: minimum number of worker threads which are kept spare
# MaxSpareThreads: maximum number of worker threads which are kept spare
# ThreadsPerChild: constant number of worker threads in each server process
# MaxRequestsPerChild: maximum number of requests a server process serves

StartServers 2
MaxClients 150
MinSpareThreads 25
MaxSpareThreads 75
ThreadsPerChild 25
MaxRequestsPerChild 0


#
# Listen: Allows you to bind Apache to specific IP addresses and/or
# ports, in addition to the default. See also the
# directive.
#
# Change this to Listen on specific IP addresses as shown below to
# prevent Apache from glomming onto all bound IP addresses (0.0.0.0)
#
#Listen 12.34.56.78:80
Listen 80

#
# Dynamic Shared Object (DSO) Support
#
# To be able to use the functionality of a module which was built as a DSO you
# have to place corresponding `LoadModule' lines at this location so the
# directives contained in it are actually available _before_ they are used.
# Statically compiled modules (those listed by `httpd -l') do not need
# to be loaded here.
#
# Example:
# LoadModule foo_module modules/mod_foo.so
#
LoadModule auth_basic_module modules/mod_auth_basic.so
LoadModule auth_digest_module modules/mod_auth_digest.so
LoadModule authn_file_module modules/mod_authn_file.so
LoadModule authn_alias_module modules/mod_authn_alias.so
LoadModule authn_anon_module modules/mod_authn_anon.so
LoadModule authn_dbm_module modules/mod_authn_dbm.so
LoadModule authn_default_module modules/mod_authn_default.so
LoadModule authz_host_module modules/mod_authz_host.so
LoadModule authz_user_module modules/mod_authz_user.so
LoadModule authz_owner_module modules/mod_authz_owner.so
LoadModule authz_groupfile_module modules/mod_authz_groupfile.so
LoadModule authz_dbm_module modules/mod_authz_dbm.so
LoadModule authz_default_module modules/mod_authz_default.so
LoadModule ldap_module modules/mod_ldap.so
LoadModule authnz_ldap_module modules/mod_authnz_ldap.so
LoadModule include_module modules/mod_include.so
LoadModule log_config_module modules/mod_log_config.so
LoadModule logio_module modules/mod_logio.so
LoadModule env_module modules/mod_env.so
LoadModule ext_filter_module modules/mod_ext_filter.so
LoadModule mime_magic_module modules/mod_mime_magic.so
LoadModule expires_module modules/mod_expires.so
LoadModule deflate_module modules/mod_deflate.so
LoadModule headers_module modules/mod_headers.so
LoadModule usertrack_module modules/mod_usertrack.so
LoadModule setenvif_module modules/mod_setenvif.so
LoadModule mime_module modules/mod_mime.so
LoadModule dav_module modules/mod_dav.so
LoadModule status_module modules/mod_status.so
LoadModule autoindex_module modules/mod_autoindex.so
LoadModule info_module modules/mod_info.so
LoadModule dav_fs_module modules/mod_dav_fs.so
LoadModule vhost_alias_module modules/mod_vhost_alias.so
LoadModule negotiation_module modules/mod_negotiation.so
LoadModule dir_module modules/mod_dir.so
LoadModule actions_module modules/mod_actions.so
LoadModule speling_module modules/mod_speling.so
LoadModule userdir_module modules/mod_userdir.so
LoadModule alias_module modules/mod_alias.so
LoadModule rewrite_module modules/mod_rewrite.so
LoadModule proxy_module modules/mod_proxy.so
LoadModule proxy_balancer_module modules/mod_proxy_balancer.so
LoadModule proxy_ftp_module modules/mod_proxy_ftp.so
LoadModule proxy_http_module modules/mod_proxy_http.so
LoadModule proxy_connect_module modules/mod_proxy_connect.so
LoadModule cache_module modules/mod_cache.so
LoadModule suexec_module modules/mod_suexec.so
LoadModule disk_cache_module modules/mod_disk_cache.so
LoadModule cgi_module modules/mod_cgi.so

#
# The following modules are not loaded by default:
#
#LoadModule cern_meta_module modules/mod_cern_meta.so
#LoadModule asis_module modules/mod_asis.so

#
# Load config files from the config directory "/etc/httpd/conf.d".
#
Include conf.d/*.conf

#
# ExtendedStatus controls whether Apache will generate "full" status
# information (ExtendedStatus On) or just basic information (ExtendedStatus
# Off) when the "server-status" handler is called. The default is Off.
#
#ExtendedStatus On

#
# If you wish httpd to run as a different user or group, you must run
# httpd as root initially and it will switch.
#
# User/Group: The name (or #number) of the user/group to run httpd as.
# . On SCO (ODT 3) use "User nouser" and "Group nogroup".
# . On HPUX you may not be able to use shared memory as nobody, and the
# suggested workaround is to create a user www and use that user.
# NOTE that some kernels refuse to setgid(Group) or semctl(IPC_SET)
# when the value of (unsigned)Group is above 60000;
# don't use Group #-1 on these systems!
#
User apache
Group apache

### Section 2: 'Main' server configuration
#
# The directives in this section set up the values used by the 'main'
# server, which responds to any requests that aren't handled by a
# definition. These values also provide defaults for
# any containers you may define later in the file.
#
# All of these directives may appear inside containers,
# in which case these default settings will be overridden for the
# virtual host being defined.
#

#
# ServerAdmin: Your address, where problems with the server should be
# e-mailed. This address appears on some server-generated pages, such
# as error documents. e.g. admin@your-domain.com
#
ServerAdmin root@localhost

#
# ServerName gives the name and port that the server uses to identify itself.
# This can often be determined automatically, but we recommend you specify
# it explicitly to prevent problems during startup.
#
# If this is not set to valid DNS name for your host, server-generated
# redirections will not work. See also the UseCanonicalName directive.
#
# If your host doesn't have a registered DNS name, enter its IP address here.
# You will have to access it by its address anyway, and this will make
# redirections work in a sensible way.
#
#ServerName www.example.com:80

#
# UseCanonicalName: Determines how Apache constructs self-referencing
# URLs and the SERVER_NAME and SERVER_PORT variables.
# When set "Off", Apache will use the Hostname and Port supplied
# by the client. When set "On", Apache will use the value of the
# ServerName directive.
#
UseCanonicalName Off

#
# DocumentRoot: The directory out of which you will serve your
# documents. By default, all requests are taken from this directory, but
# symbolic links and aliases may be used to point to other locations.
#
DocumentRoot "/var/www/html"

#
# Each directory to which Apache has access can be configured with respect
# to which services and features are allowed and/or disabled in that
# directory (and its subdirectories).
#
# First, we configure the "default" to be a very restrictive set of
# features.
#

Options FollowSymLinks
AllowOverride None


#
# Note that from this point forward you must specifically allow
# particular features to be enabled - so if something's not working as
# you might expect, make sure that you have specifically enabled it
# below.
#

#
# This should be changed to whatever you set DocumentRoot to.
#


#
# Possible values for the Options directive are "None", "All",
# or any combination of:
# Indexes Includes FollowSymLinks SymLinksifOwnerMatch ExecCGI MultiViews
#
# Note that "MultiViews" must be named *explicitly* --- "Options All"
# doesn't give it to you.
#
# The Options directive is both complicated and important. Please see
# http://httpd.apache.org/docs/2.2/mod/core.html#options
# for more information.
#
Options Indexes FollowSymLinks

#
# AllowOverride controls what directives may be placed in .htaccess files.
# It can be "All", "None", or any combination of the keywords:
# Options FileInfo AuthConfig Limit
#
AllowOverride None

#
# Controls who can get stuff from this server.
#
Order allow,deny
Allow from all



#
# UserDir: The name of the directory that is appended onto a user's home
# directory if a ~user request is received.
#
# The path to the end user account 'public_html' directory must be
# accessible to the webserver userid. This usually means that ~userid
# must have permissions of 711, ~userid/public_html must have permissions
# of 755, and documents contained therein must be world-readable.
# Otherwise, the client will only receive a "403 Forbidden" message.
#
# See also: http://httpd.apache.org/docs/misc/FAQ.html#forbidden
#

#
# UserDir is disabled by default since it can confirm the presence
# of a username on the system (depending on home directory
# permissions).
#
UserDir disabled

#
# To enable requests to /~user/ to serve the user's public_html
# directory, remove the "UserDir disabled" line above, and uncomment
# the following line instead:
#
#UserDir public_html



#
# Control access to UserDir directories. The following is an example
# for a site where these directories are restricted to read-only.
#
#
# AllowOverride FileInfo AuthConfig Limit
# Options MultiViews Indexes SymLinksIfOwnerMatch IncludesNoExec
#
# Order allow,deny
# Allow from all
#
#
# Order deny,allow
# Deny from all
#
#

#
# DirectoryIndex: sets the file that Apache will serve if a directory
# is requested.
#
# The index.html.var file (a type-map) is used to deliver content-
# negotiated documents. The MultiViews Option can be used for the
# same purpose, but it is much slower.
#
DirectoryIndex index.html index.html.var

#
# AccessFileName: The name of the file to look for in each directory
# for additional configuration directives. See also the AllowOverride
# directive.
#
AccessFileName .htaccess

#
# The following lines prevent .htaccess and .htpasswd files from being
# viewed by Web clients.
#

Order allow,deny
Deny from all


#
# TypesConfig describes where the mime.types file (or equivalent) is
# to be found.
#
TypesConfig /etc/mime.types

#
# DefaultType is the default MIME type the server will use for a document
# if it cannot otherwise determine one, such as from filename extensions.
# If your server contains mostly text or HTML documents, "text/plain" is
# a good value. If most of your content is binary, such as applications
# or images, you may want to use "application/octet-stream" instead to
# keep browsers from trying to display binary files as though they are
# text.
#
DefaultType text/plain

#
# The mod_mime_magic module allows the server to use various hints from the
# contents of the file itself to determine its type. The MIMEMagicFile
# directive tells the module where the hint definitions are located.
#

# MIMEMagicFile /usr/share/magic.mime
MIMEMagicFile conf/magic


#
# HostnameLookups: Log the names of clients or just their IP addresses
# e.g., www.apache.org (on) or 204.62.129.132 (off).
# The default is off because it'd be overall better for the net if people
# had to knowingly turn this feature on, since enabling it means that
# each client request will result in AT LEAST one lookup request to the
# nameserver.
#
HostnameLookups Off

#
# EnableMMAP: Control whether memory-mapping is used to deliver
# files (assuming that the underlying OS supports it).
# The default is on; turn this off if you serve from NFS-mounted
# filesystems. On some systems, turning it off (regardless of
# filesystem) can improve performance; for details, please see
# http://httpd.apache.org/docs/2.2/mod/core.html#enablemmap
#
#EnableMMAP off

#
# EnableSendfile: Control whether the sendfile kernel support is
# used to deliver files (assuming that the OS supports it).
# The default is on; turn this off if you serve from NFS-mounted
# filesystems. Please see
# http://httpd.apache.org/docs/2.2/mod/core.html#enablesendfile
#
#EnableSendfile off

#
# ErrorLog: The location of the error log file.
# If you do not specify an ErrorLog directive within a
# container, error messages relating to that virtual host will be
# logged here. If you *do* define an error logfile for a
# container, that host's errors will be logged there and not here.
#
ErrorLog logs/error_log

#
# LogLevel: Control the number of messages logged to the error_log.
# Possible values include: debug, info, notice, warn, error, crit,
# alert, emerg.
#
LogLevel warn

#
# The following directives define some format nicknames for use with
# a CustomLog directive (see below).
#
LogFormat "%h %l %u %t \"%r\" %>s %b \"%{Referer}i\" \"%{User-Agent}i\"" combined
LogFormat "%h %l %u %t \"%r\" %>s %b" common
LogFormat "%{Referer}i -> %U" referer
LogFormat "%{User-agent}i" agent

# "combinedio" includes actual counts of actual bytes received (%I) and sent (%O); this
# requires the mod_logio module to be loaded.
#LogFormat "%h %l %u %t \"%r\" %>s %b \"%{Referer}i\" \"%{User-Agent}i\" %I %O" combinedio

#
# The location and format of the access logfile (Common Logfile Format).
# If you do not define any access logfiles within a
# container, they will be logged here. Contrariwise, if you *do*
# define per- access logfiles, transactions will be
# logged therein and *not* in this file.
#
#CustomLog logs/access_log common

#
# If you would like to have separate agent and referer logfiles, uncomment
# the following directives.
#
#CustomLog logs/referer_log referer
#CustomLog logs/agent_log agent

#
# For a single logfile with access, agent, and referer information
# (Combined Logfile Format), use the following directive:
#
CustomLog logs/access_log combined

#
# Optionally add a line containing the server version and virtual host
# name to server-generated pages (internal error documents, FTP directory
# listings, mod_status and mod_info output etc., but not CGI generated
# documents or custom error documents).
# Set to "EMail" to also include a mailto: link to the ServerAdmin.
# Set to one of: On | Off | EMail
#
ServerSignature On

#
# Aliases: Add here as many aliases as you need (with no limit). The format is
# Alias fakename realname
#
# Note that if you include a trailing / on fakename then the server will
# require it to be present in the URL. So "/icons" isn't aliased in this
# example, only "/icons/". If the fakename is slash-terminated, then the
# realname must also be slash terminated, and if the fakename omits the
# trailing slash, the realname must also omit it.
#
# We include the /icons/ alias for FancyIndexed directory listings. If you
# do not use FancyIndexing, you may comment this out.
#
Alias /icons/ "/var/www/icons/"


Options Indexes MultiViews FollowSymLinks
AllowOverride None
Order allow,deny
Allow from all


#
# WebDAV module configuration section.
#

# Location of the WebDAV lock database.
DAVLockDB /var/lib/dav/lockdb


#
# ScriptAlias: This controls which directories contain server scripts.
# ScriptAliases are essentially the same as Aliases, except that
# documents in the realname directory are treated as applications and
# run by the server when requested rather than as documents sent to the client.
# The same rules about trailing "/" apply to ScriptAlias directives as to
# Alias.
#
ScriptAlias /cgi-bin/ "/var/www/cgi-bin/"

#
# "/var/www/cgi-bin" should be changed to whatever your ScriptAliased
# CGI directory exists, if you have that configured.
#

AllowOverride None
Options None
Order allow,deny
Allow from all


#
# Redirect allows you to tell clients about documents which used to exist in
# your server's namespace, but do not anymore. This allows you to tell the
# clients where to look for the relocated document.
# Example:
# Redirect permanent /foo http://www.example.com/bar

#
# Directives controlling the display of server-generated directory listings.
#

#
# IndexOptions: Controls the appearance of server-generated directory
# listings.
#
IndexOptions FancyIndexing VersionSort NameWidth=* HTMLTable Charset=UTF-8

#
# AddIcon* directives tell the server which icon to show for different
# files or filename extensions. These are only displayed for
# FancyIndexed directories.
#
AddIconByEncoding (CMP,/icons/compressed.gif) x-compress x-gzip

AddIconByType (TXT,/icons/text.gif) text/*
AddIconByType (IMG,/icons/image2.gif) image/*
AddIconByType (SND,/icons/sound2.gif) audio/*
AddIconByType (VID,/icons/movie.gif) video/*

AddIcon /icons/binary.gif .bin .exe
AddIcon /icons/binhex.gif .hqx
AddIcon /icons/tar.gif .tar
AddIcon /icons/world2.gif .wrl .wrl.gz .vrml .vrm .iv
AddIcon /icons/compressed.gif .Z .z .tgz .gz .zip
AddIcon /icons/a.gif .ps .ai .eps
AddIcon /icons/layout.gif .html .shtml .htm .pdf
AddIcon /icons/text.gif .txt
AddIcon /icons/c.gif .c
AddIcon /icons/p.gif .pl .py
AddIcon /icons/f.gif .for
AddIcon /icons/dvi.gif .dvi
AddIcon /icons/uuencoded.gif .uu
AddIcon /icons/script.gif .conf .sh .shar .csh .ksh .tcl
AddIcon /icons/tex.gif .tex
AddIcon /icons/bomb.gif core

AddIcon /icons/back.gif ..
AddIcon /icons/hand.right.gif README
AddIcon /icons/folder.gif ^^DIRECTORY^^
AddIcon /icons/blank.gif ^^BLANKICON^^

#
# DefaultIcon is which icon to show for files which do not have an icon
# explicitly set.
#
DefaultIcon /icons/unknown.gif

#
# AddDescription allows you to place a short description after a file in
# server-generated indexes. These are only displayed for FancyIndexed
# directories.
# Format: AddDescription "description" filename
#
#AddDescription "GZIP compressed document" .gz
#AddDescription "tar archive" .tar
#AddDescription "GZIP compressed tar archive" .tgz

#
# ReadmeName is the name of the README file the server will look for by
# default, and append to directory listings.
#
# HeaderName is the name of a file which should be prepended to
# directory indexes.
ReadmeName README.html
HeaderName HEADER.html

#
# IndexIgnore is a set of filenames which directory indexing should ignore
# and not include in the listing. Shell-style wildcarding is permitted.
#
IndexIgnore .??* *~ *# HEADER* README* RCS CVS *,v *,t

#
# DefaultLanguage and AddLanguage allows you to specify the language of
# a document. You can then use content negotiation to give a browser a
# file in a language the user can understand.
#
# Specify a default language. This means that all data
# going out without a specific language tag (see below) will
# be marked with this one. You probably do NOT want to set
# this unless you are sure it is correct for all cases.
#
# * It is generally better to not mark a page as
# * being a certain language than marking it with the wrong
# * language!
#
# DefaultLanguage nl
#
# Note 1: The suffix does not have to be the same as the language
# keyword --- those with documents in Polish (whose net-standard
# language code is pl) may wish to use "AddLanguage pl .po" to
# avoid the ambiguity with the common suffix for perl scripts.
#
# Note 2: The example entries below illustrate that in some cases
# the two character 'Language' abbreviation is not identical to
# the two character 'Country' code for its country,
# E.g. 'Danmark/dk' versus 'Danish/da'.
#
# Note 3: In the case of 'ltz' we violate the RFC by using a three char
# specifier. There is 'work in progress' to fix this and get
# the reference data for rfc1766 cleaned up.
#
# Catalan (ca) - Croatian (hr) - Czech (cs) - Danish (da) - Dutch (nl)
# English (en) - Esperanto (eo) - Estonian (et) - French (fr) - German (de)
# Greek-Modern (el) - Hebrew (he) - Italian (it) - Japanese (ja)
# Korean (ko) - Luxembourgeois* (ltz) - Norwegian Nynorsk (nn)
# Norwegian (no) - Polish (pl) - Portugese (pt)
# Brazilian Portuguese (pt-BR) - Russian (ru) - Swedish (sv)
# Simplified Chinese (zh-CN) - Spanish (es) - Traditional Chinese (zh-TW)
#
AddLanguage ca .ca
AddLanguage cs .cz .cs
AddLanguage da .dk
AddLanguage de .de
AddLanguage el .el
AddLanguage en .en
AddLanguage eo .eo
AddLanguage es .es
AddLanguage et .et
AddLanguage fr .fr
AddLanguage he .he
AddLanguage hr .hr
AddLanguage it .it
AddLanguage ja .ja
AddLanguage ko .ko
AddLanguage ltz .ltz
AddLanguage nl .nl
AddLanguage nn .nn
AddLanguage no .no
AddLanguage pl .po
AddLanguage pt .pt
AddLanguage pt-BR .pt-br
AddLanguage ru .ru
AddLanguage sv .sv
AddLanguage zh-CN .zh-cn
AddLanguage zh-TW .zh-tw

#
# LanguagePriority allows you to give precedence to some languages
# in case of a tie during content negotiation.
#
# Just list the languages in decreasing order of preference. We have
# more or less alphabetized them here. You probably want to change this.
#
LanguagePriority en ca cs da de el eo es et fr he hr it ja ko ltz nl nn no pl pt pt-BR ru sv zh-CN zh-TW

#
# ForceLanguagePriority allows you to serve a result page rather than
# MULTIPLE CHOICES (Prefer) [in case of a tie] or NOT ACCEPTABLE (Fallback)
# [in case no accepted languages matched the available variants]
#
ForceLanguagePriority Prefer Fallback

#
# Specify a default charset for all content served; this enables
# interpretation of all content as UTF-8 by default. To use the
# default browser choice (ISO-8859-1), or to allow the META tags
# in HTML content to override this choice, comment out this
# directive:
#
AddDefaultCharset UTF-8

#
# AddType allows you to add to or override the MIME configuration
# file mime.types for specific file types.
#
#AddType application/x-tar .tgz

#
# AddEncoding allows you to have certain browsers uncompress
# information on the fly. Note: Not all browsers support this.
# Despite the name similarity, the following Add* directives have nothing
# to do with the FancyIndexing customization directives above.
#
#AddEncoding x-compress .Z
#AddEncoding x-gzip .gz .tgz

# If the AddEncoding directives above are commented-out, then you
# probably should define those extensions to indicate media types:
#
AddType application/x-compress .Z
AddType application/x-gzip .gz .tgz

#
# MIME-types for downloading Certificates and CRLs
#
AddType application/x-x509-ca-cert .crt
AddType application/x-pkcs7-crl .crl

#
# AddHandler allows you to map certain file extensions to "handlers":
# actions unrelated to filetype. These can be either built into the server
# or added with the Action directive (see below)
#
# To use CGI scripts outside of ScriptAliased directories:
# (You will also need to add "ExecCGI" to the "Options" directive.)
#
#AddHandler cgi-script .cgi

#
# For files that include their own HTTP headers:
#
#AddHandler send-as-is asis

#
# For type maps (negotiated resources):
# (This is enabled by default to allow the Apache "It Worked" page
# to be distributed in multiple languages.)
#
AddHandler type-map var

#
# Filters allow you to process content before it is sent to the client.
#
# To parse .shtml files for server-side includes (SSI):
# (You will also need to add "Includes" to the "Options" directive.)
#
AddType text/html .shtml
AddOutputFilter INCLUDES .shtml

#
# Action lets you define media types that will execute a script whenever
# a matching file is called. This eliminates the need for repeated URL
# pathnames for oft-used CGI file processors.
# Format: Action media/type /cgi-script/location
# Format: Action handler-name /cgi-script/location
#

#
# Customizable error responses come in three flavors:
# 1) plain text 2) local redirects 3) external redirects
#
# Some examples:
#ErrorDocument 500 "The server made a boo boo."
#ErrorDocument 404 /missing.html
#ErrorDocument 404 "/cgi-bin/missing_handler.pl"
#ErrorDocument 402 http://www.example.com/subscription_info.html
#

#
# Putting this all together, we can internationalize error responses.
#
# We use Alias to redirect any /error/HTTP_.html.var response to
# our collection of by-error message multi-language collections. We use
# includes to substitute the appropriate text.
#
# You can modify the messages' appearance without changing any of the
# default HTTP_.html.var files by adding the line:
#
# Alias /error/include/ "/your/include/path/"
#
# which allows you to create your own set of files by starting with the
# /var/www/error/include/ files and
# copying them to /your/include/path/, even on a per-VirtualHost basis.
#

Alias /error/ "/var/www/error/"




AllowOverride None
Options IncludesNoExec
AddOutputFilter Includes html
AddHandler type-map var
Order allow,deny
Allow from all
LanguagePriority en es de fr
ForceLanguagePriority Prefer Fallback


# ErrorDocument 400 /error/HTTP_BAD_REQUEST.html.var
# ErrorDocument 401 /error/HTTP_UNAUTHORIZED.html.var
# ErrorDocument 403 /error/HTTP_FORBIDDEN.html.var
# ErrorDocument 404 /error/HTTP_NOT_FOUND.html.var
# ErrorDocument 405 /error/HTTP_METHOD_NOT_ALLOWED.html.var
# ErrorDocument 408 /error/HTTP_REQUEST_TIME_OUT.html.var
# ErrorDocument 410 /error/HTTP_GONE.html.var
# ErrorDocument 411 /error/HTTP_LENGTH_REQUIRED.html.var
# ErrorDocument 412 /error/HTTP_PRECONDITION_FAILED.html.var
# ErrorDocument 413 /error/HTTP_REQUEST_ENTITY_TOO_LARGE.html.var
# ErrorDocument 414 /error/HTTP_REQUEST_URI_TOO_LARGE.html.var
# ErrorDocument 415 /error/HTTP_UNSUPPORTED_MEDIA_TYPE.html.var
# ErrorDocument 500 /error/HTTP_INTERNAL_SERVER_ERROR.html.var
# ErrorDocument 501 /error/HTTP_NOT_IMPLEMENTED.html.var
# ErrorDocument 502 /error/HTTP_BAD_GATEWAY.html.var
# ErrorDocument 503 /error/HTTP_SERVICE_UNAVAILABLE.html.var
# ErrorDocument 506 /error/HTTP_VARIANT_ALSO_VARIES.html.var




#
# The following directives modify normal HTTP response behavior to
# handle known problems with browser implementations.
#
BrowserMatch "Mozilla/2" nokeepalive
BrowserMatch "MSIE 4\.0b2;" nokeepalive downgrade-1.0 force-response-1.0
BrowserMatch "RealPlayer 4\.0" force-response-1.0
BrowserMatch "Java/1\.0" force-response-1.0
BrowserMatch "JDK/1\.0" force-response-1.0

#
# The following directive disables redirects on non-GET requests for
# a directory that does not include the trailing slash. This fixes a
# problem with Microsoft WebFolders which does not appropriately handle
# redirects for folders with DAV methods.
# Same deal with Apple's DAV filesystem and Gnome VFS support for DAV.
#
BrowserMatch "Microsoft Data Access Internet Publishing Provider" redirect-carefully
BrowserMatch "MS FrontPage" redirect-carefully
BrowserMatch "^WebDrive" redirect-carefully
BrowserMatch "^WebDAVFS/1.[0123]" redirect-carefully
BrowserMatch "^gnome-vfs/1.0" redirect-carefully
BrowserMatch "^XML Spy" redirect-carefully
BrowserMatch "^Dreamweaver-WebDAV-SCM1" redirect-carefully

#
# Allow server status reports generated by mod_status,
# with the URL of http://servername/server-status
# Change the ".example.com" to match your domain to enable.
#
#
# SetHandler server-status
# Order deny,allow
# Deny from all
# Allow from .example.com
#

#
# Allow remote server configuration reports, with the URL of
# http://servername/server-info (requires that mod_info.c be loaded).
# Change the ".example.com" to match your domain to enable.
#
#
# SetHandler server-info
# Order deny,allow
# Deny from all
# Allow from .example.com
#

#
# Proxy Server directives. Uncomment the following lines to
# enable the proxy server:
#
#
#ProxyRequests On
#
#
# Order deny,allow
# Deny from all
# Allow from .example.com
#

#
# Enable/disable the handling of HTTP/1.1 "Via:" headers.
# ("Full" adds the server version; "Block" removes all outgoing Via: headers)
# Set to one of: Off | On | Full | Block
#
#ProxyVia On

#
# To enable a cache of proxied content, uncomment the following lines.
# See http://httpd.apache.org/docs/2.2/mod/mod_cache.html for more details.
#
#
# CacheEnable disk /
# CacheRoot "/var/cache/mod_proxy"
#
#

#
# End of proxy directives.

### Section 3: Virtual Hosts
#
# VirtualHost: If you want to maintain multiple domains/hostnames on your
# machine you can setup VirtualHost containers for them. Most configurations
# use only name-based virtual hosts so the server doesn't need to worry about
# IP addresses. This is indicated by the asterisks in the directives below.
#
# Please see the documentation at
#
# for further details before you try to setup virtual hosts.
#
# You may use the command line option '-S' to verify your virtual host
# configuration.

#
# Use name-based virtual hosting.
#
NameVirtualHost 192.168.11.18:80
#
# NOTE: NameVirtualHost cannot be used without a port specifier
# (e.g. :80) if mod_ssl is being used, due to the nature of the
# SSL protocol.
#

#
# VirtualHost example:
# Almost any Apache directive may go into a VirtualHost container.
# The first VirtualHost section is used for requests without a known
# server name.
#
#
# AllowOverride None
# Options None
# Order allow,deny
# Allow from all
#

#
# ServerAdmin webmaster@dummy-host.example.com
# DocumentRoot /www/docs/dummy-host.example.com
# ServerName dummy-host.example.com
# ErrorLog logs/dummy-host.example.com-error_log
# CustomLog logs/dummy-host.example.com-access_log common
#

ServerAdmin station18.samyang.com.tw
DocumentRoot /var/www/html
ServerName station18.samyang.com.tw
# ErrorLog logs/dummy-host.example.com-error_log
# CustomLog logs/dummy-host.example.com-access_log common

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

1、 開啟核心支援IPV6:
1、 Linux 從kernel 2.2.0後就支援IPV6。
2、 早期的kernel要支援ipv6需要自行編譯kernel,並自行安裝支援IPV6的套件。
3、 依目前的版本來看,在安裝時就會將IPV6編譯進去。而且基本的套件都已內建安裝完成。
4、 在Os 下開啟ipv6:
(1) /etc/modprobe.conf

(2)modprobe –c |grep ipv6





二、Server:
1、 先在/etc/sysconfig/network-script/ifcfg-eth2內設好ipv6的ip address。

2、 /etc/dhcp6s.conf(DHCPV6 Server 的主要設定都在這)

3、 /etc/sysconfig/network


4、 /etc/sysconfig/dhcp6s


5、


(1) 關閉ipv4防火牆
(2) 關閉ipv6防火牆
(3) 開啟dhcpv6
(4) 檢查dhcpv6是否啟動











三、Client:
1、 用上面的方法看核心是否有支援IPV6。
2、 /etc/sysconfig/network設定成跟Server端一樣。
3、 dhcp6c eth0


四、測試:-
用ping6 的指令來對Server做測試:

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

可以利用 stdout及stderr 處理
sleep 300 & echo $! > /tmp/pid & 2> 1 & #會將pid 記錄在/tmp/pid內
如果要刪除可以
kill $(cat /tmp/pid)

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

終於!Linus Torvalds 早些時候發佈了備受矚目的 Linux Kernel 3.0 新一代系統內核的正式版本,一個新的時代也由此開啟。

Linux Kernel 的上一個版本是 2.6.39,也是 2.6 系列的第 39 次升級維護。從改進幅度上看,Linux Kernel 3.0 其實完全可以叫做 2.6.40,但這年頭版本號為王,3.0 要好看得多。

Linus Torvalds在發佈聲明中說:“2.6 的日子結束了,3.0 來了。這也為下一個內核版本敞開了大門,也就是 3.1。穩定升級版會取第三位小數,所以第一個穩定更新將是 3.0.1。”

Linux Kernel 3.0 經過了七個 RC 候選版才完成正式版本,主要新特性有:

- Btrfs 檔案系統自動磁碟重組、性能改進和檢查
- 支援 sendmmsg() 函式呼叫,UDP 發送性能提升20%,介面發送性能提升約 30%
- 支持 XEN dom0
- 支援應用緩存清理 (CleanCache)
- 支持柏克萊封包篩檢程式 (Berkeley Packet Filter) 即時過濾,配合 libpcap/tcpdump 提升包過濾規則的運行效率
- 支援無線局域網 (WLAN) 喚醒
- 支援非特殊授權的 ICMP_ECHO 函數
- 支持高精度計時器 Alarm-timers
- 支援 setns() syscall,更好地命名空間管理
- 支援微軟 Kinect 體感設備
- 支援 AMD Llano APU 處理器
- 支援 Intel iwlwifi 105/135 無線網卡
- 支援 Intel C600 SAS 控制器
- 支援雷淩 Ralink RT5370 無線網卡
- 支援多種 Realtek RTL81xx 系列網卡
- 大量新驅動
- 大量 bug 修正和改進

Linux Kernel 3.0 原始程式碼下載:

ftp://ftp.kernel.org/pub/linux/kernel/v3.0/linux-3.0.tar.bz2

發佈聲明:

https://lkml.org/lkml/2011/7/21/455

更新日誌:

http://kernelnewbies.org/Linux_3.0

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

1、開啟telnet
vi /etc/xinetd.d/telnet

找到 disable = yes 將 yes 改成 no 。

/etc/init.d/xinetd restart

默認的情況之下不允許 root 以 Telnet 進入 Linux 主機 。

若要允許root用戶登入,可用下列方法:

vi /etc/pam.d/login

#auth required pam_securetty.so



mv /etc/securetty /etc/securetty.bak (建議使用)

2、開啟tftp
vi /etc/xinetd.d/tftp


找到 disable = yes 將 yes 改成 no 。

/etc/init.d/xinetd restart

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

一、Linux分支:
Red Hat RHEL
Centos
Fedora
Scientific

Novell SLES
OpenSuSe

Debian Debian
Untubu

FreeBSD FreeBSD

二、Linux特性:
1、自由度高:
大家都有在windows上體會到有些功能可能跟本就用不到,可是在安裝時就是沒有選擇的權力,甚至還會被強迫裝上。但是在linux中,所以的套件都可以自由選擇,甚至可以在系統上安裝最小的架構,讓系統可以發揮最大的效能。
2、穩定性:
大家在Windows上常常會遇到軟體不明的原因關掉,或是在處理資料時,因為資料流過大,系統不明死當。以上的問題,我可以担保在Linux上你們一定不太會遇到。因為Linux系統的穩定是數一數二的,所以在大部份的重要機構上都會以Linux為主幹來架構。
3、強大的網路功能:
大家知道外面賣的Router、Switch、防火牆都可以用Linux來架構嗎?甚至連google的Server都是用Linux來組成的。因為Linux的網路功能過於強大,所以許多知名網路服務商都是利用Linux來架構Server。
4、設備獨立性:
設備獨立性是指操作系統把所有外部設備統一當作成文件來看待,只要安裝它們的驅動程序,任何用戶都可以像使用文件一樣,操縱、使用這些設備,而不必知道它們的具體存在形式。
  具有設備獨立性的操作系統,通過把每一個外圍設備看作一個獨立文件來簡化增加新設備的工作。當需要增加新設備時、系統管理員就在內核中增加必要的連接。 這種連接(也稱作設備驅動程序)保證每次調用設備提供服務時,內核以相同的方式來處理它們。當新的及更好的外設被開發並交付給用戶時,操作允許在這些設備 連接到內核後,就能不受限制地立即訪問它們。設備獨立性的關鍵在於內核的適應能力。其他操作系統只允許一定數量或一定種類的外部設備連接。而設備獨立性的 操作系統能夠容納任意種類及任意數量的設備,因為每一個設備都是通過其與內核的專用連接獨立進行訪問。
  Linux 是具有設備獨立性的操作系統,它的內核具有高度適應能力,隨著更多的編碼員加入Linux編程,會有更多硬體設備加入到各種Linux內核和發行版本中。 另外,由於用戶可以免費得到Linux的內核源代碼,因此,用戶可以修改內核源代碼,以便適應新增加的外部設備。
5、可靠的系統安全 :
  Linux採取了許多安全技術措施,包括對讀、寫進行權限控制、帶保護的子系統、審計跟蹤、核心授權等,這為網絡多用戶環境中的用戶提供了必要的安全保障。
6、良好的可移植性 :
  可移植性是指將操作系統從一個平台轉移到另一個平台使它仍然能按其自身的方式運行的能力。
  Linux是一種可移植的操作系統,能夠在從微型計算機到大型計算機的任何環境中和任何平台上運行。可移植性為運行Linux的不同計算機平台與其他任何機器進行準確而有效的通信提供了手段,不需要另外增加特殊的和昂貴的通信接口。

三、Suse跟Red Hat的比較:
Red Ha是一個符合大眾需求的最優版本。在服務器和桌面系統中它都工作得很好。Red Hat的唯一缺陷是kernel方面,因為Red Hat是用自行重編的kernel,這使得它難於按用戶的需求進行定製。
在SuSE操作系統下,可以非常方便地訪問Windows硬碟,這使得兩種平台之間的切換,以及使用雙系統啟動變得更容易。SuSE的硬體檢測非常優秀(因為跟Oracle 和IBM合作),該版本在服務器和工作站上都用得很好。SuSE擁有界面友好的安裝過程,還有圖形管理工具(yast),可方便地訪問Windows磁盤,對於終端用戶和管理員來說使用它同樣方便,這使它成為了一個強大的服務器平台。
四、Linux 跟Windows比較:
1、系統架構:
Linux的原始碼級別的可定製性:可滿足用戶對高效能?高效率或介面等涉及用戶體驗的方面高度的需求。 Windows的封閉特性導致了架構的不透明,普遍被認為是一種混合核心型的作業系統,部分圖形介面的程式碼處在核心狀態執行,因此Windows圖形介面的反應速度上要高於GNU/Linux,但也因此使圖形介面的錯誤有可能導致整個系統故障。
2、軟體種類:
Windows以商業軟體為主,Linux則以自由軟體為主。由於大多數人缺乏使用自由軟體的習慣,使得『找不到相應的應用軟體』成為Windows用戶轉換至Linux平台的一大阻力。
3、在地化:
因為有商業利益的驅動,在地化方面Windows做得較好。特別在語言一致性、格式設置、字體和翻譯水準等方面。
4、安全性:
現階段Linux在安全性方面要優於Windows。在Windows上,病毒、木馬幾乎每天都有,但 Linux 本身並不執行副檔名,是由權限來判別是否執行該檔案,所以病毒、木馬量非常少,而bug也是在可接受範圍之內。
5、穩定性:
Windows經常因為運行應用程序而死機;Linux極少發生這種情況
6、硬體支持:
Windows支援度很高(絕大多數的硬體廠商都是針對Windows做設計);Linux的硬體支援稍差(僅在特別新的硬件上),比如RHEL4不支援SATA硬碟,而RHEL4U2就開始支援SATA技術。
7、多工、多使用者:
與 Windows 系統不同的,Linux 主機上可以同時允許多人上線來工作,並且資源的分配較為公平,比起 Windows 的單人假多工系統要穩定。這個多人多工可是 Unix-Like 上面相當好的一個功能,怎麼說呢?你可以在一部 Linux 主機上面規劃出不同等級的使用者,而且每個使用者登入系統時的工作環境都可以不相同,此外,還可以允許不同的使用者在同一個時間登入主機,以同時使用主機的資源。
文章標籤

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

開機流程

1、載入 BIOS 的硬體資訊與進行自我測試,並依據設定取得第一個可開機的裝置;
2、讀取並執行第一個開機裝置內 MBR 的 boot Loader (亦即是 lilo、grub, spfdisk 等程式);
3、依據 boot loader 的設定載入 Kernel ,Kernel 會開始偵測硬體與載入驅動程式;
4、在硬體驅動成功後,Kernel 會主動呼叫 init 程式,而 init 會取得 run-level 資訊;
5、init 執行 /etc/rc.d/rc.sysinit 檔案來準備軟體執行的作業環境 (如網路、時區等);
6、init 執行 run-level 的各個服務之啟動 (script 方式);
7、init 執行 /etc/rc.d/rc.local 檔案;
8、init 執行終端機模擬程式 mingetty 來啟動 login 程式,最後就等待使用者登入
文章標籤

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

ethtool ethX //查詢ethX網口基本設置
ethtool –h //顯示ethtool的命令幫助(help)
ethtool –i ethX //查詢ethX網口的相關信息
ethtool –d ethX //查詢ethX網口註冊性信息
ethtool –r ethX //重置ethX網口到自適應模式
ethtool –S ethX //查詢ethX網口收發包統計
ethtool –s ethX [speed 10|100|1000]\ //設置網口速率10/100/1000M
[duplex half|full]\ //設置網口半/全雙工
[autoneg on|off]\ //設置網口是否自協商
[port tp|aui|bnc|mii]\ //設置網口類型
[phyad N]\
[xcvr internal|exteral]\
[wol p|u|m|b|a|g|s|d...]\
[sopass xx:yy:zz:aa:bb:cc]\
[msglvl N]

舉例:
1)[root@linux /]# ethtool eth1
Settings for eth1:
Supported ports: [ TP ]
Supported link modes: 10baseT/Half 10baseT/Full
100baseT/Half 100baseT/Full
1000baseT/Full
Supports auto-negotiation: Yes
Advertised link modes: 10baseT/Half 10baseT/Full
100baseT/Half 100baseT/Full
1000baseT/Full
Advertised auto-negotiation: Yes
Speed: 1000Mb/s
Duplex: Full
Port: Twisted Pair
PHYAD: 0
Transceiver: internal
Auto-negotiation: on
Supports Wake-on: umbg
Wake-on: d
Link detected: yes
2)[root@linux /]# ethtool -i eth1
driver: e1000
version: 5.0.43-k1
firmware-version: N/A
bus-info: 06:08.1
3)[root@linux /]# ethtool -S eth1
NIC statistics:
rx_packets: 58068300
tx_packets: 87124083
rx_bytes: 1589713008
tx_bytes: 2165825901
rx_errors: 0
tx_errors: 0
rx_dropped: 0
tx_dropped: 0
multicast: 0
collisions: 0
rx_length_errors: 0
rx_over_errors: 0
rx_crc_errors: 0
rx_frame_errors: 0
rx_fifo_errors: 0
rx_missed_errors: 0
tx_aborted_errors: 0
tx_carrier_errors: 0
tx_fifo_errors: 0
tx_heartbeat_errors: 0
tx_window_errors: 0
4)[root@linux /]# ethtool -s eth1 autoneg off speed 100 duplex full

相關:
1)[root@linux /]# which ethtool
/sbin/ethtool
2)[root@linux /]# rpm -qf /sbin/ethtool
ethtool-1.6-5
3)怎樣使ethtool設置永久保存在網絡設備中?
解決方法一:
ethtool設置可通過/etc/sysconfig/network-scripts/ifcfg-ethX文件保存,從而在設備下次啟動時激活選項。
例如:ethtool -s eth0 speed 100 duplex full autoneg off
此指令將eth0設備設置為全雙工自適應,速度為100Mbs。若要eth0啟動時設置這些參數, 修改文件/etc/sysconfig/network-scripts/ifcfg-eth0 ,添加如下一行:
ETHTOOL_OPTS="speed 100 duplex full autoneg off"
解決方法二:
將ethtool設置寫入/etc/rc.d/rc.local之中。
文章標籤

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

一、RHEL
1、vim /etc/sysconfig/network-scripts/ifcfg-bond0
DEVICE=bond0
BOOTPROTO=static
BROADCAST=192.168.4.255
IPADDR=192.168.4.100
NETWORK=192.168.4.0
NETMASK=255.255.255.0
GATEWAY=192.168.4.1
ONBOOT=yes

2、vim /etc/sysconfig/network-scripts/ifcfg-eth1
DEVICE=eth1
BOOTPROTO=static
ONBOOT=yes

3、vim /etc/sysconfig/network-scripts/ifcfg-eth2
DEVICE=eth2
BOOTPROTO=static
ONBOOT=yes

4、vim /etc/modprobe.conf(RHEL 5)
vim /etc/modprobe.d/dist.conf(RHEL 6)
加入這兩行
alias bond0 bonding

options bond0 miimon=80 mode=1
#mode=1 自動備援模式,其中一條線若斷線,其他線路將會自動備援
#mode=0 平衡負載模式,有自動備援,但需要"Switch"支援及設定

5、vim /etc/rc.d/rc.local
加入
ifenslave bond0 eth1 eth2


二、SLES
1、vim /etc/sysconfig/network/ifcfg-bond0
BOOTPROTO='static'
BROADCAST='192.168.4.255'
IPADDR='192.168.4.30'
NETWORK='192.168.4.0'
NETMASK='255.255.255.0'
STARTMODE='onboot'
BONDING_MASTER='yes'
BONDING_MODULE_OPTS='mode=0 miimon=100 use_carrier=0'
#BONDING_SLAVE0='bus-pci-0000:00:12.0'
#BONDING_SLAVE1='bus-pci-0000:00:13.0'
BONDING_SLAVE0='eth2'
BONDING_SLAVE1='eth3'

2、vim /etc/sysconfig/network/ifcfg-eth2
BOOTPROTO='none'
BROADCAST=''
ETHTOOL_OPTIONS=''
IPADDR=''
MTU=''
NAME='82572EI Gigabit Ethernet Controller (Copper)'
NETMASK=''
NETWORK=''
REMOTE_IPADDR=''
STARTMODE='off'
USERCONTROL='no'


3、vim /etc/sysconfig/network/ifcfg-eth3
BOOTPROTO='none'
BROADCAST=''
ETHTOOL_OPTIONS=''
IPADDR=''
MTU=''
NAME='82574L Gigabit Network Connection'
NETMASK=''
NETWORK=''
REMOTE_IPADDR=''
STARTMODE='off'
USERCONTROL='no'

4、rcnetwork restart

5、vim /etc/modprobe.conf
加入
alias bond0 bonding
options bond0 miimon=100 mode=1
文章標籤

Yang Chun Yi 發表在 痞客邦 留言(0) 人氣()

1 2
